Specifications

  • Manometer Used
    628H
  • Full Scale Range
    1 Torr
  • Sensor Temperature
    100°C
  • Power Requirements
    ±15 VDC ± 5% @ 0.35 amps
  • Output Signal
    0 – 10 VDC into >10 kOhm load (Process Baratron capacitance manometer)
  • Flange Size
    NW16
  • Fitting Type
    ISO-KF
  • Compliance
    CE
  • Calibration Orientation
    vertical
  • Trip Relays
    Two (2) independently-adjusted electromechanical relays, UL listed, rated at 1 Amp @ 30 VDC or 0.3 Amp @ 30 VAC. Standard relay settings are Trip Relay A energizes >5 Torr and Trip Relay B energizes below 9.5 Torr. Other relay settings available
