ISO-MF Vacuum Flange Rotatable Bolt Rings
Overview
- Bolt ISO-MF flanges to ISO-BF flanges
- Same diameter and bolt pattern as ISO-BF flanges
- Aluminum construction with SS retaining ring
- NW63 to NW500 flange sizes
Products
| Compare | Description | Drawings, CAD & Specs | Availability | Price | |||
|---|---|---|---|---|---|---|---|
|
100762806 Rotatable Bolt Ring, ISO-MF Size NW63 Vacuum Flange, Aluminum |
|
$123 |
|
|||
|
100762808 Rotatable Bolt Ring, ISO-MF Size NW80 Vacuum Flange, Aluminum |
|
$115 |
|
|||
|
100762810 Rotatable Bolt Ring, ISO-MF Size NW100 Vacuum Flange, Aluminum |
|
$136 |
|
|||
|
100762816 Rotatable Bolt Ring, ISO-MF Size NW160 Vacuum Flange, Aluminum |
|
$246 |
|
|||
|
100762820 Rotatable Bolt Ring, ISO-MF Size NW200 Vacuum Flange, Aluminum | $382 |
|
||||
|
|
100762825 Rotatable Bolt Ring, ISO-MF Size NW250 Vacuum Flange, Aluminum | $2,364 |
|
||||
|
|
100762832 Rotatable Bolt Ring, ISO-MF Size NW320 Vacuum Flange, Aluminum | $2,311 |
|
||||
|
|
100762840 Rotatable Bolt Ring, ISO-MF Size NW400 Vacuum Flange, Aluminum | $1,214 |
|
||||
|
|
100762850 Rotatable Bolt Ring, ISO-MF Size NW500 Vacuum Flange, Aluminum | $2,454 |
|
Specifications
-
Component TypeRotatable Bolt Ring
-
SeriesSeries 76
-
Flange TypeISO-MF
-
MaterialAluminum
-
Retaining RingStainless Steel
Features
Resources
Literature
- Series 76 ISO-Universal Vacuum Components & Fittings (2.8 MB, PDF)
