Communication & Fieldbus Coupler Modules
Overview
MKS communication and fieldbus coupler modules (CM) provide a compact, customizable, and cost effective solution for standalone manual control, data logging, or distributed I/O. The CM can be implemented as a standalone unit, supporting manual, remote control capabilities with the Controls Workbench application, with built in data logging and process monitoring, or with LabVIEW.
- Interfaces with MKS controls workbench, for process monitoring & remote control
- Supports fieldbuses & control networks like EtherCAT, Modbus TCP/IP, Ethernet/IP
- Scalable to any number of MKS I/O slices to create a distributed I/O support for hundreds of channels
- Compact footprint
- Interface with LabVIEW
Products
| Compare | Description | Drawings, CAD & Specs | Availability | Price | |||
|---|---|---|---|---|---|---|---|
|
AS11870G-02 Communications & Fieldbus Coupler Module, Modbus TCP/IP | $595.00 |
|
||||
|
|
AS11870G-04 Communications & Fieldbus Coupler Module, EtherCAT | $609.00 |
|
Specifications
-
ProcessorARM Cortex-M4, 100 MHz
-
Operating SystemRTOS
-
Internal RAM256 MB
-
Expandable MemoryMicro SD, 1 or 2 GB
-
Dimensions35 mm x 125 mm x 92.3 mm (1.4 x 3.3 x 4.9 inches) (W x H x D)
-
Network InterfaceUSB OTG, 1 x RJ45 (Ethernet) 10/100Mbits/s
-
I/O InterfaceL-Bus
-
User InterfaceLEDs
-
Programming LanguagesIEC61131-3
-
Code Space1 MB
-
Power Supply24 VDC
-
Operating Temperature0 - 50°C
-
Storage Temperature-40 to 85°C
-
Humidity5-85% (non-condensing)
-
AltitudeUp to 2000 meters
