ISO-MF Vacuum Flange 4-Way Crosses

ISO-MF Vacuum Flange 4-Way Crosses

Products
Features
Resources
Contact Us

Overview

Four-way cross fittings have one inlet and three outlets and can be used as cross branch lines. Our 4-way crosses have the same size ISO-MF flange on all ports and are made with 304 stainless steel.

4-way crosses for branching
304 Stainless Steel construction
NW63 to NW320 flange sizes
Standard face to centerline distance

See All Features

Products

		Compare	Description	Compatibility	sortOrder	rankScore	ranking	Drawings, CAD & Specs		Flange Size	Length	Modulus	Availability	Featured Item	Price		Brand
		100761506 4-Way Cross Fitting, NW63 Size ISO-KF Flanges, 304 Stainless Steel $650 Show	100761506 4-Way Cross Fitting, NW63 Size ISO-KF Flanges, 304 Stainless Steel	UNIVERSAL	0.0	1.0	0.0		0.0	NW63	6.92 in. (176 mm)	3.46 in. (88 mm)	Show		$650
		100761508 4-Way Cross Fitting, NW80 Size ISO-KF Flanges, 304 Stainless Steel $820 Show	100761508 4-Way Cross Fitting, NW80 Size ISO-KF Flanges, 304 Stainless Steel	UNIVERSAL	0.0	1.0	0.0		0.0	NW80	7.72 in. (196 mm)	3.86 in. (98 mm)	Show		$820
		100761510 4-Way Cross Fitting, NW100 Size ISO-KF Flanges, 304 Stainless Steel $894 Show	100761510 4-Way Cross Fitting, NW100 Size ISO-KF Flanges, 304 Stainless Steel	UNIVERSAL	0.0	1.0	0.0		0.0	NW100	8.50 in. (216 mm)	4.25 in. (108 mm)	Show		$894
		100761516 4-Way Cross Fitting, NW160 Size ISO-KF Flanges, 304 Stainless Steel $1,339 Show	100761516 4-Way Cross Fitting, NW160 Size ISO-KF Flanges, 304 Stainless Steel	UNIVERSAL	0.0	1.0	0.0		0.0	NW160	10.86 in. (276 mm)	5.43 in. (138 mm)	Show		$1,339
		100761520 4-Way Cross Fitting, NW200 Size ISO-KF Flanges, 304 Stainless Steel $4,714 Show	100761520 4-Way Cross Fitting, NW200 Size ISO-KF Flanges, 304 Stainless Steel	UNIVERSAL	0.0	1.0	0.0		0.0	NW200	13.22 in. (336 mm)	6.61 in. (168 mm)	Show		$4,714
		100761525 4-Way Cross Fitting, NW250 Size ISO-KF Flanges, 304 Stainless Steel $2,785 Show	100761525 4-Way Cross Fitting, NW250 Size ISO-KF Flanges, 304 Stainless Steel	UNIVERSAL	0.0	1.0	0.0		0.0	NW250	16.38 in. (416 mm)	8.19 in. (208 mm)	Show		$2,785
		100761532 4-Way Cross Fitting, NW320 Size ISO-KF Flanges, 304 Stainless Steel $8,325 Show	100761532 4-Way Cross Fitting, NW320 Size ISO-KF Flanges, 304 Stainless Steel	UNIVERSAL	0.0	1.0	0.0		0.0	NW320	25.20 in. (640 mm)	12.60 in. (320 mm)	Show		$8,325

Show All

Specifications

Component Type

4-Way Cross
Series

Series 76

Flange Type

ISO-MF
Material

304 Stainless Steel

Features

Resources

Literature

Series 76 ISO-Universal Vacuum Components & Fittings (2.8 MB, PDF)
