ISO-MF Thick Wall Metal Vacuum Hose

ISO-MF Thick Wall Metal Vacuum Hose

Products
Features
Resources
Contact Us

Overview

Thick wall metal vacuum hose is constructed from formed Stainless Steel with the hose buttwelded. It is unsheathed and offered in 500 or 1000 mm lengths for NW63 to NW250 size ISO-MF flanges.

Unsheathed Stainless Steel with thick hose wall
500 or 1000 mm lengths
NW63 to NW250 ISO-MF flange sizes

See All Features

Products

		Compare	Description	Compatibility	sortOrder	rankScore	ranking	Drawings, CAD & Specs		Flange Size	Length	Static Bend Radius	Availability	Featured Item	Price		Brand
		100763606 Metal Wall Vacuum Hose, NW63 ISO-MF, 500 mm Length, 0.3 mm Hose Wall $555 Show	100763606 Metal Wall Vacuum Hose, NW63 ISO-MF, 500 mm Length, 0.3 mm Hose Wall	UNIVERSAL	0.0	1.0	0.0		0.0	NW 63	19.69 in. (500 mm)	6.5 in.	Show		$555
		100763608 Metal Wall Vacuum Hose, NW80 ISO-MF, 500 mm Length, 0.3 mm Hose Wall $660 Show	100763608 Metal Wall Vacuum Hose, NW80 ISO-MF, 500 mm Length, 0.3 mm Hose Wall	UNIVERSAL	0.0	1.0	0.0		0.0	NW 80	19.69 in. (500 mm)	7.0 in.	Show		$660
		100763610 Metal Wall Vacuum Hose, NW100 ISO-MF, 500 mm Length, 0.3 mm Hose Wall $646 Show	100763610 Metal Wall Vacuum Hose, NW100 ISO-MF, 500 mm Length, 0.3 mm Hose Wall	UNIVERSAL	0.0	1.0	0.0		0.0	NW 100	19.69 in. (500 mm)	11.0 in.	Show		$646
		100763616 Metal Wall Vacuum Hose, NW160 ISO-MF, 500 mm Length, 0.3 mm Hose Wall $948 Show	100763616 Metal Wall Vacuum Hose, NW160 ISO-MF, 500 mm Length, 0.3 mm Hose Wall	UNIVERSAL	0.0	1.0	0.0		0.0	NW 160	19.69 in. (500 mm)	17.0 in.	Show		$948
		100763620 Metal Wall Vacuum Hose, NW200 ISO-MF, 500 mm Length, 0.3 mm Hose Wall $1,930 Show	100763620 Metal Wall Vacuum Hose, NW200 ISO-MF, 500 mm Length, 0.3 mm Hose Wall	UNIVERSAL	0.0	1.0	0.0		0.0	NW 200	19.69 in. (500 mm)	18.0 in.	Show		$1,930
		100763625 Metal Wall Vacuum Hose, NW250 ISO-MF, 500 mm Length, 0.3 mm Hose Wall $2,119 Show	100763625 Metal Wall Vacuum Hose, NW250 ISO-MF, 500 mm Length, 0.3 mm Hose Wall	UNIVERSAL	0.0	1.0	0.0		0.0	NW 250	19.69 in. (500 mm)	24.0 in.	Show		$2,119
		100763706 Metal Wall Vacuum Hose, NW63 ISO-MF, 1000 mm Length, 0.3 mm Hose Wall $661 Show	100763706 Metal Wall Vacuum Hose, NW63 ISO-MF, 1000 mm Length, 0.3 mm Hose Wall	UNIVERSAL	0.0	1.0	0.0		0.0	NW 63	39.40 in. (1000 mm)	6.5 in.	Show		$661
		100763708 Metal Wall Vacuum Hose, NW80 ISO-MF, 1000 mm Length, 0.3 mm Hose Wall $741 Show	100763708 Metal Wall Vacuum Hose, NW80 ISO-MF, 1000 mm Length, 0.3 mm Hose Wall	UNIVERSAL	0.0	1.0	0.0		0.0	NW 80	39.40 in. (1000 mm)	7.0 in.	Show		$741
		100763710 Metal Wall Vacuum Hose, NW100 ISO-MF, 1000 mm Length, 0.3 mm Hose Wall $893 Show	100763710 Metal Wall Vacuum Hose, NW100 ISO-MF, 1000 mm Length, 0.3 mm Hose Wall	UNIVERSAL	0.0	1.0	0.0		0.0	NW 100	39.40 in. (1000 mm)	11.0 in.	Show		$893
		100763716 Metal Wall Vacuum Hose, NW160 ISO-MF, 1000 mm Length, 0.3 mm Hose Wall $1,714 Show	100763716 Metal Wall Vacuum Hose, NW160 ISO-MF, 1000 mm Length, 0.3 mm Hose Wall	UNIVERSAL	0.0	1.0	0.0		0.0	NW 160	39.40 in. (1000 mm)	17.0 in.	Show		$1,714
		100763720 Metal Wall Vacuum Hose, NW200 ISO-MF, 1000 mm Length, 0.3 mm Hose Wall $1,891 Show	100763720 Metal Wall Vacuum Hose, NW200 ISO-MF, 1000 mm Length, 0.3 mm Hose Wall	UNIVERSAL	0.0	1.0	0.0		0.0	NW 200	39.40 in. (1000 mm)	18.0 in.	Show		$1,891
		100763725 Metal Wall Vacuum Hose, NW250 ISO-MF, 1000 mm Length, 0.3 mm Hose Wall $2,363 Show	100763725 Metal Wall Vacuum Hose, NW250 ISO-MF, 1000 mm Length, 0.3 mm Hose Wall	UNIVERSAL	0.0	1.0	0.0		0.0	NW 250	39.40 in. (1000 mm)	24.0 in.	Show		$2,363

Show All

Specifications

Component Type

Metal Wall Vacuum Hose
Series

Series 76
Flange Type

ISO-MF

Material

Stainless Steel
Wall Thickness

0.12 in. (0.3 mm)

Features

Resources

Literature

Series 76 ISO-Universal Vacuum Components & Fittings (2.8 MB, PDF)

Need help?

Contact an Applications Specialist by sending us an email
